Fractal Full Tower Design Pop XL Silent Black Solid, FD-C-POS1X-01

external
2x 5.25"
Internal
3x 2.5"/3.5" (transverse, HDD rails), 2x 2.5", 1x 2.5"/3.5" (optional), 2x 2.5" (optional)
front I/O
2x USB-A 3.0 (5Gb/?s), 1x microphone, 1x headphone
PCI-slots
8
Fan(s) (front)
3x 120mm, 1200rpm or 2x 140mm (optional)
Fan(s) (rear)
1x 120mm, 1200rpm or 1x 140mm (optional)
Fans (left)
not available
Fans right
not available
Fan(s) (top)
2x 140mm (optional)
Fan(s) (bottom)
not available
Fans (other)
not available
radiator sizes
120/?140/?240/?280/?360mm front, 120/?240/?280mm top, 120/?140mm rear
Motherboard
to ATX (280mm wide)
Supported motherboards
Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (12"x11")
Power supply
ATX (max. 205mm deep)
Power supply position
bottom
CPU Coolers
max. 185mm height
Graphics Cards
max. 430mm
Colour
black, inside black
Lighting
without Illumination
Dimensions (WxHxD)
230x520x522mm
Capacity
62.43l
Weight
10.42kg
Type
Midi-Tower
front
closed
above
closed, detachable cover, mainly fan grill, insulation mat inside
below
partially closed, fan grill rear, dust filter outdoor
left
closed, insulation mat inside
right
closed, insulation mat inside
aft
partially closed, fan grill right top, PCI slots (8x horizontal)
front I/O position
Housing side: top, Height: front, position: right
Special features
Cable Management, dust filter, noise-insulated
Note
Mainboard and case manufacturers refer to different dimensions as E-ATX. E-ATX/SSI EEB mainboard dimensions of 305x330mm respectively 12"x13" are not supported.
