Fractal Mini Tower Design Meshify 2 Mini White TG Clear Tint, mATX, FD-C-MES2M-02

100.200.073External not available
Internal 2x 2.5"/3.5" (transverse, HDD rails), 2x 2.5", 2x 2.5" (optional)
front I/O 1x USB-C 3.1 (10Gb/s, 20-Pin Key-A Header), 2x USB-A 3.0 (5Gb/s), 1x microphone, 1x headphone
PCI-slots 4
Fan(s) (front) 1x 140mm, 1000rpm, 0.71mmH2O, 116m3/h, 18.9dB(A) or 3x 120mm (optional) or 2x 140mm (optional)
Fan(s) (rear) 1x 120mm, 1200rpm, 0.88mmH2O, 90.6m3/h, 19.4dB(A)
Fans (left) not available
Fans right not available
Fan(s) (top) 2x 140mm (optional)
Fan(s) (bottom) 1x 120mm (optional)
Fans (other) not available
radiator sizes 120/140/240/280mm front, 120/240mm top, 120mm rear, 120mm bottom
Motherboard to µATX
Supported motherboards Mini-ITX (6.7"x6.7")/mini-DTX (6.7"x8")/DTX (9.6"x8")/µATX (9.6"x9.6")
Power supply ATX (max. 200mm deep without HDD-cage, 165mm with HDD-cage)
Power supply position bottom
CPU Coolers max. 167mm height
Graphics Cards max. 331mm (without front fan, 306mm with front fan)
Colour white/black, inside black/white
Lighting without Illumination
Dimensions (WxHxD) 205x406x396mm
Capacity 32.96l
Weight 6.62kg
Type Mini-Tower
front Mesh, dust filter inside
above partially closed, mainly fan grill, dust filter inside
below partially closed, mainly fan grill, dust filter outdoor
left closed, glass
right closed
aft partially closed, fan grill right top, PCI slots (4x horizontal)
front I/O position Housing side: top, Height: front, position: centered
Special features Cable Management, dust filter, side panel window made out of glass
