Lian Li Midi Tower O11 Vision, glass window, Black, O11VX, 4718466014139

external
not available
Internal
2x 2.5"/3.5" (transverse, HDD cage), 3x 2.5"
Connectors
1x USB-C 3.1 (10Gb/?s, 20-Pin Key-A Header), 2x USB-A 3.0 (5Gb/?s), 1x 3.5mm jack (Line-In/?Out)
PCI-slots
7
Fan(s) (front)
not available
Fan(s) (rear)
2x 120mm (optional)
Fans (left)
not available
Fans right
3x 120mm (optional) or 2x 140mm (optional)
Fan(s) (top)
not available
Fan(s) (bottom)
3x 140mm (optional) or 3x 120mm (optional)
Fans (other)
not available
radiator sizes
not available front, not available top, 240mm rear, 280/?360mm right, 360mm bottom
Motherboard
to ATX (279mm wide)
Supported motherboards
Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (12"x11")
Power supply
ATX (max. 200mm deep)
Power supply position
bottom (vertical)
Colour
black, inside black
Lighting
RGB-Header 3-Pin ARGB (+5V/?DATA/?GND), integrated LED control, integrated RGB-LED lighting
Dimensions (WxHxD)
304x464.5x480mm
Capacity
67.78l
Type
Midi-Tower
front
closed, glass
above
closed, glass
below
partially closed, mainly fan grill, dust filter outdoor
left
closed, glass
right
partially closed, Mesh, mainly fan grill
aft
partially closed, fan grill right top, PCI slots (7x horizontal)
front I/O position
Housing side: front, Height: bottom, position: right
Motherboard-Alignment
motherboard-Alignment: to left
Special features
aluminum housing, Cable Management, graphics card vertical mountable (optional), side panel window made out of glass, Mehrkammerdesign
note to E-ATX
Mainboard and case manufacturers refer to different dimensions as E-ATX. E-ATX/SSI EEB mainboard dimensions of 305x330mm respectively 12"x13" are not supported.
