Lian Li Midi Tower O11 Air Mini, glass window, White, O11AMW, 4718466010698

external
not available
Internal
4x 2.5"/3.5" (HDD rails), 2x 2.5"
front I/O
1x USB-C 3.1 (10Gb/?s, 20-Pin Key-A Header), 2x USB-A 3.0 (5Gb/?s), 1x headphone, 1x microphone
PCI-slots
7 or 5
Fan(s) (front)
2x 140mm or 2x 120mm (optional)
Fan(s) (rear)
1x 120mm
Fans (left)
not available
Fans right
2x 120mm (optional)
Fan(s) (top)
3x 120mm (optional) or 2x 140mm (optional)
Fan(s) (bottom)
2x 140mm (optional)
Fans (other)
not available
radiator sizes
240/?280mm front, 240/?280mm top, 240/?280mm bottom, 240mm right
Motherboard
to ATX (280mm wide)
Supported motherboards
Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (12"x11")
Power supply
ATX (max. 200mm deep)
Power supply position
bottom (vertical)
CPU Coolers
max. 170mm height
Graphics Cards
max. 362mm
Colour
white, inside white
Lighting
without Illumination
Dimensions (WxHxD)
288x384x400mm
Capacity
44.24l
Type
Midi-Tower
front
partially closed, partially Mesh
above
partially closed, partially Mesh, mainly fan grill
below
partially closed, mainly fan grill, dust filter outdoor
left
closed, glass
right
partially closed, mainly fan grill, Mesh
aft
partially closed, fan grill right top, PCI slots bottom (modular, 7x horizontal or 5x horizontal)
front I/O position
Housing side: top, Height: front, position: right
Special features
Cable Management, side panel window made out of glass, dust filter, Mehrkammerdesign
Note
Mainboard and case manufacturers refer to different dimensions as E-ATX. E-ATX/SSI EEB mainboard dimensions of 305x330mm respectively 12"x13" are not supported.
