Lian Li Full Tower V3000 Plus, glass window, Black, V3000PX, 4718466012913

external
not available
Internal
8x 2.5"/3.5" (transverse, HDD rails), 8x 2.5"
Connectors
1x USB-C 3.0 (5Gb/?s, 19-Pin Header, System 1, System 2), 2x USB-A 3.0 (5Gb/?s, System 1, System 2), 1x 3.5mm jack (Line-In/?Out, System 1, System 2)
PCI-slots
11 (entire); System1: 8; System2: 3
Fan(s) (front)
4x 120mm (optional) or 3x 140mm (optional) (konfigurationsabhängig!)
Fan(s) (rear)
3x 120mm (optional) or 2x 140mm (optional) (konfigurationsabhängig!)
Fans (left)
not available
Fans right
not available
Fan(s) (top)
4x 120mm (optional) or 3x 140mm (optional) or 2x 200mm (optional) (konfigurationsabhängig!)
Fan(s) (bottom)
4x 120mm (optional) or 3x 140mm (optional) (konfigurationsabhängig!)
Fans (other)
3x 120mm (optional) or 3x 140mm (optional) (konfigurationsabhängig!)
radiator sizes
420/?480mm front, 420/?480mm top, 280/?360mm rear, 420/?480mm bottom, 360/?420mm other (konfigurationsabhängig!)
Motherboard
to E-ATX (SSI EEB, 12"x13", System1), to Mini-ITX (System2)
Supported motherboards
Mini-ITX (6.7"x6.7", System1, System2)/µATX (9.6"x9.6", System1)/ATX (12"x9.6", System1)/E-ATX (SSI EEB, 12"x13", System1)
Power supply
ATX (max. 220mm deep, System1), SFX-L (System2)
Power supply position
bottom (vertical, two Power Supplies possible)
CPU Coolers
max. 198mm height (198mm System1, 80mm System2)
Graphics Cards
max. 589mm (at enclosure configuration Standard, 358mm at enclosure configuration Rotated, 320mm for System2 at enclosure configuration Dual System)
Colour
black, inside black
Lighting
RGB-Header 3-Pin ARGB (+5V/?DATA/?GND), integrated LED control, integrated RGB-LED lighting
Dimensions (WxHxD)
279x674x678.5mm
Capacity
127.59l
Type
Big-Tower
front
partially closed, mainly Mesh
above
partially closed, mainly fan grill
below
partially closed, mainly fan grill, fan grill left, dust filter outdoor
left
partially closed, partially Mesh, mainly glass, ventilation slots bottom
right
partially closed, partially Mesh, ventilation slots bottom
aft
partially closed, fan grill right top, PCI slots (8x horizontal System1, 3x optional vertical System2), 1x tube-/?Rohrdurchführung right centered, 1x tube-/?Rohrdurchführung bottom
front I/O position
Housing side: top, Height: front, position: centered
Motherboard-Alignment
motherboard-alignment modular: to left (System1) or to top (at enclosure configuration Dual-System, System2); Connectors: connectors rear (at enclosure configuration Standard) or connectors bottom (under cover, at enclosure configuration Rotated) or connectors rear (at enclosure configuration Dual-System)
Special features
aluminum housing, Dual System, graphics card hanging/?standing mountable (at enclosure configuration Rotated), side panel window made out of glass
Note
declaration the maximum möglichen fan- and radiator installation options. various enclosure configurations (Standard/?Rotated/?Dual-System) support various fan- and radiator configurations.
note #2
At enclosure configuration Norm: fan rear: 1x 120mm (optional) or 1x 140mm (optional); fan other: 3x 120mm (optional) or 3x 140mm (optional); Radiator sizes: 420/?480mm front, 420/?480mm top, 420/?480mm bottom, 360/?420mm other
enclosure configuration Rotated: fan rear: 3x 120mm (optional) or 2x 140mm (optional); fan other: 1x 120mm (optional) or 1x 140mm (optional); Radiator sizes: 420/?480mm front, 420/?480mm top, 280/?360mm rear, 420/?480mm bottom
enclosure configuration Dual-System: fan rear: 1x 120mm (optional) or 1x 140mm (optional); fan other: 2x 120mm (optional) or 2x 140mm (optional); Radiator sizes: 420/?480mm front, 480mm top, 420/?480mm bottom, 240/?280mm other
