XFX RX6750XT Core Gaming, 12GB GDDR6, RX-675TMBAF9

Video Output
Requires Expansion Slot Standard PCI Express 4.0 x16
Form Factor Full-height
Video Chipset AMD Radeon RX 6750 XT
GPU Core Name NAVI 22
GPU Core Speed 2150 MHz
GPU Core Speed Boost 2600 MHz
GPU Quantity 1
Stream Processors Quantity 2560
Compute Units Quantity 40
Texture Mapping Unit Quantity 160
Render Output Units Quantity (ROP) 64
Ray-tracing Cores Quantity 40
Max. Monitors Supports 4
2D/3D Features Dolby TrueHD and DTSHD Master Audio Support
AMD Eyefinity
AMD Virtual Super Resolution (VSR)
VR Ready
AMD Frame Rate Target Control (FRTC)
AMD FreeSync
AMD Radeon Image Sharpening
AMD FidelityFX
Video Streaming up to 8K
AMD Radeon Anti-Lag
RDNA 2 Architecture
AMD Software: Adrenalin Edition
API Supports OpenCL
DirectX 12.0
OpenGL 4.6
Memory
Video Memory Type Video Controller Memory
Memory Type GDDR6 SDRAM
Installed Video Memory Storage Capacity 12 GB
Video Memory Speed 18 Gbps
Memory Bus Bandwidth 192 bit
Memory Bandwidth 432 GB/s
Interface Provided
HDMI Interface Quantity 1
HDMI Interface Connector Type HDMI (Type A)
DisplayPort Interface Quantity 3
System Requirements
External Power 2 x 8 pin
PSU Output Power Required 650 W
Miscellaneous
Cooling System Type VGA Cooler
Card Slot Width 2.6 slot
Included Accessories Quick Start Guide
Dimensions & Weight Device
Depth (mm) 280 mm
Height (mm) 42 mm
Width (mm) 135 mm
