Sapphire RX7700XT Nitro+ Gaming OC, 12GB, GDDR6, 11335-02-20G

GPU AMD Radeon RX 7700 XT
Memory 12GB GDDR6, 192bit, 18Gbps, 2250MHz, 432GB/?s
overclock +55MHz Boost, +105MHz Game
clock Boost 2276-2599MHz
clock Base unknown
Cooling 3x Axial-fan (95mm, fan detachable) with 0dB-zero-fan-mode
TDP/TGP 245W (AMD), max. 252W (Sapphire)
Power connections 2x 8-Pin PCIe
Interfaces 2x HDMI 2.1, 2x DisplayPort 2.1
Interface PCIe 4.0 x16
Special features Backplate, LED lighting (RGB), RGB-synchronization (3-Pin ARGB)
total height Triple Slot (3 Slots)
Dimensions 320x134.85x61.57mm (LxWxH)
Type PCIe card (full height)
PCI slot bracket full height
Computing power 71.86 TFLOPS (FP16), 35.93 TFLOPS (FP32), 2.25 TFLOPS (FP64)
Chip-data
Chip-Architecture RDNA 3 (from 2022/?Q4)
Chip-title Navi 32
Chip-Configuration 54CU (3456 ALUs /? 216 TMUs /? 96 ROPs), 54 RT Cores, 2MB L2 cache, 48MB L3 cache
Chip-Manufacturing Process TSMC 5nm + TSMC 6nm
Chip size 346mm2, Multi-Chip module (3 MCM-Chiplets)
Chip-functions Raytracing, AMD Infinity cache (48MB), HDCP 2.3
API-support DirectX 12 Ultimate (12_2) /? Vulkan 1.3 /? OpenCL 2.1 /? OpenGL 4.6 /? Shader Model 6.7
Transcoding-Engine VCN 4.0, Info
encoding AV1, H.265, H.264
decoding AV1, H.265, H.264, VP9
Multi-GPU-Interface
-
