Sapphire RX7600XT Pulse Radeon, AMD, 16GB GDDR6, 11339-04-20G

GPU
AMD Radeon RX 7600 XT
Memory
16GB GDDR6, 128bit, 18Gbps, 2250MHz, 288GB/s
Clock Base
1720MHz
Clock Boost
2355-2755MHz
Overclocking -
Cooling 2x axial fan (90mm)
TDP/TGP 190W (AMD), max. 192W (Sapphire)
Power connections 2x 8-pin PCIe
Connections
2x HDMI 2.1, 2x DisplayPort 2.1 UHBR13.5
Connection
PCIe 4.0 x16 (x8)
Particularities
Backplate
Overall depth
Triple Slot (2.2 Slots)
Dimensions
250x129.25x44.56mm (LxWxH)
Construction
PCIe card (full height)
Slot bezel
full height
Computing power
45.14 TFLOPS (FP16), 22.57 TFLOPS (FP32), 0.71 TFLOPS (FP64)
Chip Data
Chip Architecture
RDNA 3 (from 2022/Q4)
Chip Designation
Navi 33 XT
Chip Configuration
32CU (2048SP / 128TMU / 64ROP), 32 RT Cores, 2MB L2 Cache, 32MB L3 Cache
Chip Manufacturing
TSMC 6nm
Chip Size
204mm2, monolithic, 13.3 billion transistors
Chip Functions
Ray tracing, AMD Infinity Cache (32MB), HDCP 2.3
API support
DirectX 12 Ultimate (12_2) / Vulkan 1.3 / OpenCL 2.2 / OpenGL 4.6 / Shader Model 6.7
Encoding
AV1, H.265, H.264
Decoding
AV1, H.265, H.264, VP9
Multi-GPU connectivity
-
Introduction (Series)
08.01.2024, Market launch: 24.01.2024, MSRP: 329 USD (AMD)
Graphic
AMD Radeon RX 7600 XT - 16GB GDDR6 - Desktop
