Phanteks Midi Tower Eclipse G360A, RGB, White, glass window, PH-EC360ATG_DMW02

external
not available
Internal
2x 2.5"/3.5" (transverse, HDD rails), 2x 2.5", 1x 2.5" (optional)
front I/O
2x USB-A 3.0 (5Gb/?s), 1x microphone, 1x headphone
PCI-slots
7
Fan(s) (front)
3x 120mm (RGB illuminated) or 2x 140mm (optional)
Fan(s) (rear)
1x 120mm (optional)
Fans (left)
not available
Fans right
not available
Fan(s) (top)
3x 120mm (optional) or 2x 140mm (optional)
Fan(s) (bottom)
not available
Fans (other)
not available
radiator sizes
120/?140/?240/?280/?360mm front, 120/?240/?360mm top, 120mm rear
Motherboard
to ATX (280mm wide)
Supported motherboards
Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (12"x11")
Power supply
ATX (max. 280mm deep with HDD-cage in rear position, 220mm deep with HDD-cage in vorderer position)
Power supply position
bottom
CPU Coolers
max. 162mm height
Graphics Cards
max. 400mm
Colour
white, inside white
Lighting
RGB-Header 3-Pin ARGB (+5V/?DATA/?GND), integrated LED control, integrated RGB-LED lighting, illuminated fan
Dimensions (WxHxD)
200x465x455mm
Capacity
42.31l
Weight
6.51kg
Type
Midi-Tower
front
Mesh
above
partially closed, mainly fan grill, dust filter outdoor
below
partially closed, fan grill rear, dust filter outdoor
left
closed, mainly glass
right
closed
aft
partially closed, fan grill right top, PCI slots (7x horizontal)
front I/O position
Housing side: top, Height: front, position: right
Special features
Cable Management, dust filter, graphics card vertical mountable (optional), side panel window made out of glass
Note
Mainboard and case manufacturers refer to different dimensions as E-ATX. E-ATX/SSI EEB mainboard dimensions of 305x330mm respectively 12"x13" are not supported.
