NZXT Midi Tower H9 Elite Black Window, CM-H91EB-01

External not available
Internal 2x 2.5"/3.5" (transverse, HDD rails), 4x 2.5"
front I/O 1x USB-C 3.1 (10Gb/s, 20-Pin Key-A Header), 2x USB-A 3.0 (5Gb/s), 1x headphone/microphone
PCI-slots 7
Fan(s) (front) not available
Fan(s) (rear) 1x 120mm, 1200rpm, 1.05mmH2O, 105.64m3/h, 25.1dB(A)
Fans (left) not available
Fans right 3x 120mm, 500-1800rpm, 2.42mmH2O, 82.59m3/h, 29dB(A) (RGB illuminated)
Fan(s) (top) 3x 120mm (optional) or 2x 140mm (optional)
Fan(s) (bottom) 3x 120mm (optional) or 2x 140mm (optional)
Fans (other) not available
radiator sizes not available front, 120/140/240/280/360mm top, 120mm rear, 120/240/360mm right
Motherboard to ATX
Supported motherboards Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")
Power supply ATX (max. 200mm deep)
Power supply position top (vertical)
CPU Coolers max. 165mm height
Graphics Cards max. 435mm
Colour black, inside black
Lighting RGB-Header, integrated LED control, illuminated fan
Dimensions (WxHxD) 290x495x466mm
Capacity 66.89l
Weight 13.10kg
Type Midi-Tower
front closed, glass
above closed, glass, ventilation slots right
below partially closed, mainly fan grill, dust filter outdoor
left closed, glass
right partially closed, mainly fan grill, Mesh, dust filter inside
aft partially closed, fan grill right centered, PCI slots (7x horizontal)
front I/O position Housing side: top, Height: front, position: right
Special features Cable Management, dust filter, side panel window made out of glass, Mehrkammerdesign, incl. fan control
