Lian Li Full Tower Odyssey X, glass window, Black, TR-01X, 4718466010438

external
not available
Internal
3x 2.5"/3.5" (transverse)
Connectors
1x USB-C 3.0 (5Gb/?s), 2x USB-A 3.0 (5Gb/?s), 1x 3.5mm jack (Line-Out), 1x 3.5mm jack (Line-In)
PCI-slots
8
Fan(s) (front)
3x 120mm (optional, at enclosure configuration Dynamic) or 2x 140mm (optional, at enclosure configuration Dynamic)
Fan(s) (rear)
not available
Fans (left)
not available
Fans right
3x 120mm (optional, at enclosure configuration Dynamic) or 2x 140mm (optional, at enclosure configuration Dynamic)
Fan(s) (top)
3x 120mm (optional, at enclosure configuration Dynamic) or 2x 140mm (optional, at enclosure configuration Dynamic)
Fan(s) (bottom)
not available
Fans (other)
not available
radiator sizes
420/?480mm front (at enclosure configuration Performance), 280/?360mm top (at enclosure configuration Performance)
Motherboard
to E-ATX (SSI EEB, 12"x13")
Supported motherboards
Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (SSI EEB, 12"x13")
Power supply
ATX (max. 280mm deep)
Power supply position
bottom (at enclosure configuration Dynamic/?Performance)
CPU Coolers
max. 170mm height
Graphics Cards
max. 423mm
Colour
black, inside black
Lighting
without Illumination
Dimensions (WxHxD)
234x558.5x575.5mm (at enclosure configuration Dynamic/?Dynamic-R), 368.6x596.7x537.1mm (at enclosure configuration Performance)
Capacity
75.21l (at enclosure configuration Dynamic/?Dynamic-R), 118.13l (at enclosure configuration Performance)
Weight
16.58kg
Type
Big-Tower
front
closed, ventilation slots centered
above
closed, ventilation slots sidewise
below
partially closed, mainly fan grill, dust filter inside
left
closed, glass
right
closed, glass
aft
partially closed, fan grill right top, PCI slots (8x horizontal)
front I/O position
Housing side: modular (front/?top), Height: modular (front/?centered), position: centered
Special features
case size/?shape changeable (configuration Dynamic/?Dynamic-R/?Performance), foldable, Cable Management, graphics card hanging/?standing mountable (at enclosure configuration Dynamic-R), I/?O-panel-position modular, side panel window made out of glass
Note
various enclosure configurations (Dynamic/?Dynamic-R/?Performance) support various fan- and radiator configurations.
