Fractal Midi Tower Design Meshify 2 Lite Black TG Light Tint, FD-C-MEL2A-03

External not available
Internal 2x 2.5"/3.5" (transverse, HDD rails), 2x 2.5", 2x 2.5"/3.5" (optional)
front I/O 1x USB-C 3.1 (10Gb/s, 20-Pin Key-A Header), 2x USB-A 3.0 (5Gb/s), 1x microphone, 1x headphone
PCI-slots 7
Fan(s) (front) 2x 140mm, 1000rpm, 19.5dB(A), 1.02mmH2O, 69.7m3/h or 3x 140mm (optional)
Fan(s) (rear) 1x 140mm, 1000rpm, 19.5dB(A), 1.02mmH2O, 69.7m3/h
Fans (left) not available
Fans right not available
Fan(s) (top) 3x 140mm (optional)
Fan(s) (bottom) 2x 140mm (optional)
Fans (other) not available
radiator sizes 120/140/240/280/360mm front, 120/240/360mm top, 120/140/240/280mm bottom, 120mm rear
Motherboard to ATX (285mm wide)
Supported motherboards Mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (12"x11.2")
Power supply ATX (max. 250mm deep)
Power supply position bottom
CPU Coolers max. 185mm height
Graphics Cards max. 451mm (476mm without front fan)
Colour black, inside black
Lighting without Illumination
Dimensions (WxHxD) 240x474x542mm
Capacity 61.66l
Weight 9.60kg
Type Midi-Tower
front I/O position Housing side: not specified, Height: not specified, position: not specified
Special features Cable Management, dust filter, side panel window made out of glass
Note Mainboard and case manufacturers refer to different dimensions as E-ATX. E-ATX/SSI EEB mainboard dimensions of 305x330mm respectively 12"x13" are not supported.
