ASUS RTX3050 DUAL-RTX3050-O8G-V2, 8GB, GDDR6, 90YV0GH6-M0NA00

GPU
NVIDIA GeForce RTX 3050
Memory
8GB GDDR6, 128bit, 14Gbps, 1750MHz, 224GB/s
Overclocking
+75MHz Boost (OC Profile), +45MHz Boost (Standard Profile)
Clock Boost
1822MHz (standard profile), 1852MHz (OC profile)
Takt Basis
1552MHz (standard profile), 1552MHz (OC profile)
Cooling
2x axial fan (100mm) with 0dB zero fan mode (up to 50°C)
TDP/TGP
130W (NVIDIA)
Electricity connections
1x 6-pin PCIe
Interfaces
1x DVI, 1x HDMI 2.1, 1x DisplayPort 1.4a
Connection
PCIe 4.0 x16 (x8)
Particularities
Clock profiles (default mode/OC mode), backplate, LED lighting (RGB)
Overall depth
Dual Slot (2 Slots)
Dimensions
200x123x38mm (LxWxH)
Construction
PCIe card (full height)
Slot bracket
full height
Computing power
9.48 TFLOPS (FP16), 9.48 TFLOPS (FP32), 0.15 TFLOPS (FP64)
Warranty
three years (processing via dealers)
Chip data
Chip Architecture
Ampere (from 2020/Q3)
Chip designation
GA106-150-KA-A1
Chip configuration
20SM (2560 ALUs / 80 TMUs / 32 ROPs), 20 RT cores, 80 tensor cores, 2MB L2 cache
Chip manufacturing
Samsung 8nm
Chip size
276mm2, monolithic, 12 billion transistors
Chip Functions
Raytracing (2nd Gen NVIDIA RTX), NVIDIA Tensor (3rd Gen), HDCP 2.3
API support
DirectX 12 Ultimate (12_2) / CUDA 8.6 / Vulkan 1.3 / OpenCL 3.0 / OpenGL 4.6 / Shader Model 6.7
Transcoding Engine
1x NVENC (7th Gen, max. Sessions: 5), 1x NVDEC (5th Gen), Info
Encoding
H.265 (4K YUV 4:2:0 / 4K YUV 4:4:4 / 4K Lossless / 8K / HEVC 10bit support / HEVC B Frame support), H.264 (YUV 4:2:0 / YUV 4:4:4 / Lossless)
Decoding
AV1 (8bit / 10bit), H.265 (8bit 4:2:0 / 10bit 4:2:0
