Asrock RX7600 Phantom Gaming OC, AMD Radeon, 8GB GDDR6, 90-GA4BZZ-00UANF

GPU
AMD Radeon RX 7600
Memory
8GB GDDR6, 128bit, 18Gbps, 2250MHz, 288GB/s
Overclocking
+100MHz Boost, +105MHz Game
Clock Boost
2355-2755MHz
Takt Basis
1720MHz
Cooling
3x axial fans (90mm, partially RGB illuminated) with 0dB zero fan mode
TDP/TGP
165W (AMD)1111
Electricity connections
1x 8-pin PCIe
Interfaces
1x HDMI 2.1, 3x DisplayPort 2.1
Connection
PCIe 4.0 x16 (x8)
Particularities
Backplate, LED lighting (RGB)
Overall depth
Triple Slot (2.4 Slots)
Dimensions
305x131x48mm (LxWxH), weight: 894g
Construction
PCIe card (full height)
Slot bracket
full height
Computing power
45.14 TFLOPS (FP16), 22.57 TFLOPS (FP32), 1.41 TFLOPS (FP64)
Chip data
Chip Architecture
RDNA 3 (from 2022/Q4)
Chip designation
Navi 33 XL
Chip configuration
32CU (2048 ALUs / 128 TMUs / 64 ROPs), 32 RT cores, 2MB L2 cache, 32MB L3 cache
Chip manufacturing
TSMC 6nm
Chip size
204mm2, monolithic, 13.3 billion transistors
Chip Functions
Raytracing, AMD Infinity Cache (32MB), HDCP 2.3
API support
DirectX 12 Ultimate (12_2) / Vulkan 1.3 / OpenCL 2.1 / OpenGL 4.6 / Shader Model 6.7
Transcoding Engine
VCN 4.0, Info
Encoding
AV1, H.265, H.264
Decoding
AV1, H.265, H.264, VP9
