Fractal Midi Tower Design Define 7 TG Dark Black, FD-C-DEF7A-03

External 1x 5.25"
Internal 6x 2.5"/3.5" (transverse, HDD rails), 2x 2.5", 8x 2.5"/3.5" (optional)
front I/O 1x USB-C 3.1 (20-Pin Key-A Header), 2x USB-A 3.0, 2x USB-A 2.0, 1x microphone, 1x headphone
PCI-slots 9 (2x Riser Card)
Fan(s) (front) 2x 140mm, 1000rpm, 116m3/h, 18.9dB(A) or 3x 140mm (optional)
Fan(s) (rear) 1x 140mm, 1000rpm, 116m3/h, 18.9dB(A)
Fans (left) not available
Fans right not available
Fan(s) (top) 3x 140mm (optional)
Fan(s) (bottom) 2x 140mm (optional)
Fans (other) not available
radiator sizes 120/140/240/280/360mm front, 120/140/240/280/360/420mm top, 120/140/240/280mm bottom, 120mm rear
Motherboard to ATX (285mm wide)
Supported motherboards mini-ITX (6.7"x6.7")/µATX (9.6"x9.6")/ATX (12"x9.6")/E-ATX (12"x11.2")
Power supply ATX (max. 250mm deep)
Power supply position bottom
CPU Coolers max. 185mm height
Graphics Cards max. 315mm (491mm without HDD-cage without front fan, 467mm without HDD-cage with front fan)
Colour black, inside black
Lighting without Illumination
Dimensions (WxHxD) 240x474x547mm
Capacity 62.23l
Weight 13.45kg
Type Midi-Tower
Special features front door, Cable Management, dust filter, incl. fan control, incl. exchangeable top-panel, side panel window made out of glass, noise-insulated
Note Mainboard and case manufacturers refer to different dimensions as E-ATX. E-ATX/SSI EEB mainboard dimensions of 305x330mm respectively 12"x13" are not supported.
