Sapphire RX7600 Pulse Gaming OC, AMD Radeon, 8GB GDDR6, 11324-01-20G

GPU AMD Radeon RX 7600
Memory 8GB GDDR6, 128bit, 18Gbps, 2250MHz, 288GB/s
overclock +100MHz Boost, +105MHz Game
clock Boost 2355-2755MHz
clock Base 1720MHz
Cooling 2x Axial-fan (90mm) with 0dB-zero-fan-mode
TDP/TGP 165W (AMD), max. 185W (Sapphire)
Power connections 1x 8-Pin PCIe
Interfaces 1x HDMI 2.1, 3x DisplayPort 2.1
Interface PCIe 4.0 x16 (x8)
Special features Backplate
total height Dual Slot
Dimensions 240x107.1x44.07mm (LxWxH)
Type PCIe card (full height)
PCI slot bracket full height
Computing power 45.14 TFLOPS (FP16), 22.57 TFLOPS (FP32), 1.41 TFLOPS (FP64)
Chip-dataChip-Architecture RDNA 3 (from 2022/Q4)
Chip-title Navi 33 XL
Chip-Configuration 32CU (2048 ALUs / 128 TMUs / 64 ROPs), 32 RT Cores, 6MB L2 cache, 32MB L3 cache
Chip-Manufacturing Process TSMC 6nm
Chip size 204mm2, monolithisch, 13.3 Mrd. Transistoren
Chip-functions Raytracing, AMD Infinity cache (32MB), HDCP 2.3
API-support DirectX 12 Ultimate (12_2) / Vulkan 1.3 / OpenCL 2.1 / OpenGL 4.6 / Shader Model 6.7
Transcoding-Engine VCN 4.0, Info
encoding AV1, H.265, H.264
decoding AV1, H.265, H.264, VP9
